Calibration gas portable

Is Your Gas Detection System In Tune?

Lack of planning can jeopardize crew safety, cargo integrity and financial performance. Is your current portable gas detection system well managed – and reliable?

Plan Ahead to Stay Safe and Compliant

According to regulations, all ships are required to carry calibration gases for portable gas detectors. These gases can often be difficult to obtain in ports on short notice. Furthermore, gas cylinders have a limited shelf life which requires them to be replaced at certain intervals.

By purchasing them in a structured manner, both time and money can be saved, and the ship will always have the correct type available on board.

The Bruusgaard system does that job for you. We have developed an optimised logistics and procurement process that ensures your safety and compliance at the lowest possible cost.

Worldwide Deliveries

We have the most common calibration gases in stock and can ship world-wide – also by air freight if required. By utilising our network of hubs for calibration gas, costly dangerous goods fees can be avoided*.

Local deliveries are available in:

– Dubai
– Shanghai
– Rotterdam
– Rio
– Singapore
– UK
– USA
– Panama
– Norway

*Special terms may apply.

Product Portfolio

Standard Calibration Gases

Please note: Shelf life depends on type of gas and varies between 1-3 years.

Product no. Calibration Gas Composition Volume
MB10013 Ammonia (NH3) 25 ppm NH3 in N2 34 L / 1 L cylinder
MB10014 50 ppm NH3 in N2 34 L / 1 L cylinder
MB10005 n-Butane 0,9% C4H10, in air 12 L / 1 L cylinder
MB10007 8% C4H10, 14% CO2, in N2 12 L / 1 L cylinder
MB10003 Carbon dioxide (CO2) 5% CO2 in N2 12 L / 1 L cylinder
MB10000 Carbon monoxide (CO) 50 ppm CO in air 12 L / 1 L cylinder
MB10015 Hydrogen sulfide (H2S) 25 ppm H2S in N2 34 L / 1 L cylinder
MB10156 50 ppm H2S in N2 34 L / 1 L cylinder
MB10008 Isobutylene (C4H8) 100 ppm C4H8, in air 12 L / 1 L cylinder
MB10009 Methane (CH4) 2,5% CH4 in air 12 L / 1 L cylinder
MB10010 15% CH4 in N2 12 L / 1 L cylinder
MB10157 99 – 99.999% CH4 12 L / 1 L cylinder
MB10004 Multimix 25 ppm H2S, 50ppm CO, 2,5% CH4, 12% O2, N2 balance 34 L / 1 L cylinder
MB10242MED 25ppm H2S, 50ppm CO, 2,2% CH4, 12% O2, N2 balance 34 L / 1 L cylinder
MB10144 25 ppm H2S, 100 ppm CO, 2,5% CH4, 18% O2, N2 balance 34 L / 1 L cylinder
MB10145 15 ppm H2S, 50 ppm CO, 2,5% CH4, 18% O2, N2 balance 34 L / 1 L cylinder
MB10006 Nitrogen pure (N2) 99.999% N2 12 L / 1 L cylinder
MB10146 Oxygen (O2) 18% O2 in N2 12 L / 1 L cylinder
MB10147 Propane C3H8 1,05% C3H8 in air 12 L / 1 L cylinder
MB10012 Z Cal gas (inert) 14% CO2 in N2 12 L / 1 L cylinder



Standard Regulators

FF-025-BR-C10 Regulator, Fixed flow 0.25 l/min C10 inlet
FF-100-0.5-BR Regulator, Fixed flow 0.5 l/min
Y114740 Regulator, Fine control w. manomenter
ODFR-1001 Regulator, Demand Flow

Useful Information

The gas cylinders are disposable, and have a volume of 1 litre. They contain 12 or 34 litres of gas. The cylinders are classified as dangerous goods for airfreight, so please account for some extra days additional transportation time.

Since the cylinders are lightweight, there will not be much difference in freight charges whether we ship 1 or 15 cylinders. Thus it is strongly recommended to structure the supply of calibration gases. We advise to order enough gas for around one year’s worth of consumption, in order to lower the freight cost per cylinder and the frequency of supply.

Do you need information about Standard Calibration Gas for Scrubber Systems? Take a look here!

Do you need information about Standard Calibration Gas for Fixed Systems? Take a look here!

Download Material Safety Data Sheet here.
